Remote Instruction 1: How to Pair my MTSKR2005WF / MTSKR1905WF Remote with Receiver?

Remote Instruction 1: How to Pair my MTSKR2005WF / MTSKR1905WF Remote with Receiver?

When you received the MTSKR1905WF / MTSKR2005WF remote, firstly you need to connect receiver to your VESC / ESC, and pair the remote with receiver.

1. If you use VESC with built-in BEC, then just need to connect the throttle wire on ESC to receiver PWM port, receiver port definition as below, same as both MTSKR2005WF and MTSKR1905WF:

Maytech MTSKR1905WF V2 IP67 Waterproof Remote Control 2.4GHz wireless hand remote compatible with VESC for Esk8 Esurf Efoil Hydrofoil RC Boat

Benjamin Vedder Electric Speed Controller, Dual VESC  V6 based Controller: SUPERFOC6.8 50A VESC6.0 based Controller / 200A VESC  V4 based Controller: VESC50A/ VESC50ADU /VESC100A  180A anti-spark switch  Application: Electric skateboard, longboard, mountainboard, all terrain offroad skateboard, fighting robots, walking robots, ROV, fishing boat, city skateboard, Esk8, eskate, e-bike, mtb e-bike, e-scooter, arm robot, combat robot, cable camera, Articulated Robots, robot dog, camera motorized dolly, lawnmower, lawnmower robot, smart robot lawnmower





2. If you use OPTO without built-in 5V BEC, then you also need to add a 5V UBEC to power the receiver, wiring diagram as below:



Speed controllers for Esurf/Efoil/Boat Motor controller and Speed controls for electric surfboard, rc trucks, rc cars, buggies, rc radio control helicopter, ducted fan jet, rc boat, fishing baitboat., Efoil, foilsurf, foilboard, foil boat, foiling boat, fishing boat, electric watercraft, hydrofoil boat, hydrofoiling boat, electric boat, motorized boat, electric hydrofoil, electric foil, jetski, jetboard, jet boat, water jet, water jet propulsion.





3. After connected correctly, then do pair steps as below:

Firstly, must turn off the receiver power first, otherwise will not be able to connect successfully.

Select【>4.Pair】and long press function button for 1 second to enter pair status. When screen shows

【Paring…】, turn on receiver and it will auto-pair with remote control in 0.5 second. Red led lights steady.

Pairing competed. Remote screen will automatically return to main menu.

If auto-pairing time is over 1 second and screen still shows【Pairing…】, pairing fails and it needs to turn off and turn on receiver again to pair them. If you don’t want to continue the pairing process, long press function button to exit to main menu.
