Next-Gen Innovation: Maytech 2-in-1 Steerable MTED70-E Electric Pod Drive Motor with Built-in ESC— Redefining Marine & Underwater Propulsion!

Next-Gen Innovation: Maytech 2-in-1 Steerable MTED70-E Electric Pod Drive Motor with Built-in ESC— Redefining Marine & Underwater Propulsion!

Whether you are an eFoil rider, Tow Boogie DIY enthusiast, or a developer of inflatable boats, ROVs/AUVs, and underwater scooters, integrating an underwater propulsion system has historically been one of the most challenging aspects of any build. Sourcing compatible waterproof ESCs, routing thick cables, ensuring watertight seals, and custom-engineering steering mechanisms add unnecessary complexity, weight, and failure points.

To solve these industry pain points once and for all, Maytech has officially launched the MTED70-E Electric Pod Drive Motor—an all-in-one underwater propulsion unit equipped with a built-in ESC and optional steerable functionality.

Click here to check more information of MTED70-E pod drive



1. Why is the MTED70-E the Ultimate Choice for Marine Propulsion?

1. All-in-One Design with Built-In ESC: Say Goodbye to Bulky Wiring & Leaks

Traditional underwater thruster setups require placing the motor in the water while keeping the Electronic Speed Controller (ESC) inside a surface dry deck. Running long three-phase power lines increases line resistance, generates unwanted heat, and creates complex waterproofing challenges.

  • Integrated ESC: The MTED70-E embeds a professional-grade ESC directly inside the waterproof motor pod, utilizing surrounding water flow for high-efficiency thermal management.

  • Plug & Play Integration: Eliminates the need for an internal ESC enclosure in your battery deck, greatly simplifying internal compartment layouts and shortening setup time.

2. Steerable Functionality: Precision Handling & Maneuverability

In addition to fixed-thruster configurations, the MTED70-E offers a steerable variant, breaking away from traditional rigid setups that rely on external rudders or differential thrust alone.

  • On inflatable boats, kayaks, and Tow Boogies, it delivers high-response vector thrust for razor-sharp steering.

  • On underwater scooters and ROVs, it allows for agile, pin-point orientation and rapid directional changes.

3. IP68 Waterproofing & Marine-Grade Corrosion Resistance

Underwater electronics demand uncompromising sealing and corrosion defenses.

  • The MTED70-E boasts an IP68 waterproof rating, using advanced ceramic and polymer dynamic shaft sealing technology.

  • Both the casing and internal rotor undergo specialized anti-corrosion treatments, ensuring long-term reliability in both freshwater lakes and harsh saltwater environments.

4. Impressive Thrust & Explosive Power

Optimized at a balanced 103KV, the MTED70-E strikes the perfect ratio between torque delivery and propeller efficiency:

  • At 36V Voltage: Reaches up to 4,464W at full throttle, delivering ~47.5 kgf of maximum thrust.

  • At 48V Voltage: Surges to 7,632W at full power (~159A peak current), generating an extraordinary ~58.5 kgf of thrust! This massive thrust makes eFoil foiling smoother, enables quick acceleration for small boats, and delivers unrelenting towing power for Tow Boogies cutting through wave crests.

5. Durable Materials & Protective Prop Guard

  • Carbon-Nylon Propeller: Constructed from high-strength PA66 + 30% Carbon Fiber, delivering optimal rigidity, lightweight performance, and impact resistance.

  • Heavy-Duty Prop Guard: Comes standard with an integrated safety cage to protect propellers from weeds, debris, and accidental contact during water activities.

2. Key Technical Specifications

  • Model: Maytech MTED70-E

  • Motor Type: Inrunner Brushless Underwater Pod Drive Motor with Built-In ESC

  • Waterproof Rating: IP68 (Submersible for deep water and marine environments)

  • Motor KV: 103 KV

  • Input Voltage Range: 30V – 60V (10S – 14S LiPo compatible)

  • Max Output Power & Thrust:

    • @ 36V: 4,464W | Max Thrust ~47.5 kgf

    • @ 48V: 7,632W | Max Thrust ~58.5 kgf

  • Propeller Material: Reinforced Nylon Carbon Fiber (PA66 + Carbon Fiber)

  • Customization Options: Custom KV ratings, cable lengths, connector types, and OEM logo branding available.

3. Versatile Applications: Unleash Unlimited Potential

Whether you are building a custom DIY project or developing commercial products, the MTED70-E seamlessly adapts to multiple applications:

  1. eFoils (Electric Hydrofoils)

    Serves as an ultra-streamlined pod drive that minimizes hydrodynamic drag, delivering an effortless glided flight over the water.

  2. Tow Boogies (Electric Towing Boards)

    Delivers up to 58.5 kgf of powerful traction to pull surfers straight into break lines.

  3. Inflatable Boats / Kayaks / Small Craft Propulsion

    Replace heavy, noisy, gas-powered outboard engines with a silent, eco-friendly, vector-steerable electric thruster.

  4. Underwater Scooters & DPVs (Diver Propulsion Vehicles)

    Compact dimensions combined with a high power-to-weight ratio make it an ideal core engine for diving equipment and underwater imaging platforms.
