This outrunner motor can be used for electric skateboard, robotics, RC airplanes, RC helicopter, UAV drones. etc.
All parts are made of a high-precision CNC machining center, and all surfaces are made with oxidation treatment. High temperature and high purity oxygen-free copper wires were used. The motors use high-grade magnets and 0.2 mm lamination to improve efficiency.
Better efficiency means you get more mechanical energy per unit of power,
After a lot of development, we have put together what we know works best for an electric skateboard or ebike motor and made it small and compact.
Model NO.: MTO5055-220-G
Idle Current: 0.5A
Max. Current: 30A
Input Volt.: 2-10s Lipo
Max. Output Watt：1170W
Max. Pull: 5400g
Rated Current:25.5A
Motor Weight: 270g
Shaft: 6mm
Motor dimension: Φ49.2x 42.5mm
Internal Resistance: 0.1022
With no Hall Sensor
Price does not include accessory
Application: for electric skateboard, ebike, electric bike, underwater robots, Marine robots, fighting robots, War robots, delivery robots, electric power tools, hydrofoil board, MegaBots, Battlebots, Robot combat, Combat Robots, etc.
Dimension:
