Brushless 6374 90/190KV Non-sealed Cover Sensored Motor for Esk8/Robots

$170.80 Regular price $299.90

Brushless 6374 190KV Non-sealed Cover Sensored Motor for Esk8/E-bike/Robots/Mountainboard/E-scooter

This hall sensor motor comes with hall sensor board. Sensored will start from a dead stop very smoothly – while sensorless you’ll likely have to kick-push and once you’re moving, even if slowly, the motor can take it from there.

All parts are made of a high-precision CNC machining center, and all surfaces are made with oxidation treatment. High temperature and high purity oxygen-free copper wires were used. The motors use high-grade magnets and 0.2 mm lamination to improve efficiency.

The closed cover enables motors have dust-proof and water-proof function

The hall-effect sensors inside tracks the motor’s position. This information permits the controller to alternate power with the right timing and in the right sequence and, voila, it spins.

Better efficiency means you get more mechanical energy per unit of power,

After a lot of development, we have put together what we know works best for an electric skateboard or ebike motor and made it small and compact.

Model NO.: MTO6374-190-HA

KV: 190

Idle Current: 0.8A

Max. Current: 65A

Input Volt.: 2-12s Lipo

Max. Output Watt: 3550W

Max. Pull: 13000g

Rated Current: 60A

Motor Weight: 825g

Shaft: 8mm

Motor dimension: Φ62.6x 74.0mm

Internal Resistance: 0.0402

With Hall Sensor

Price does not include accessory

Application: for electric skateboard, ebike, electric bike, underwater robots, Marine robots, fighting robots, War robots, delivery robots, electric power tools, hydrofoil board, MegaBots, Battlebots, Robot combat, Combat Robots, etc.
