In Stock! New Marine 32Bit 160A 60V ESC IP68 Waterproof Smaller Size for Powered Assist Foil Board Efoil
In Stock! New Marine 32Bit 160A 60V ESC IP68 Waterproof Smaller Size for Powered Assist Foil Board Efoil
Regular price
$219.70 USD
Regular price
Sale price
$219.70 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
If you want to use other cheaper but slower shipping method, please contact agnes@maytech.cn
Shipping time by DHL or UPS is fast, normally 3-7 days arrive to you.
New Marine 32Bit 160A 60V ESC IP68 Waterproof Smaller Size for Powered Assist Foil Board Efoil
Specification:
Model No.: MTSF160A-WP32
Waterproof Rank: IP68
Cont Current: 160A
Peak Current: 180A
Input Voltage: 6-14S Lipo (25V-60V)
With 5V/0.5A BEC
32BIT Micropprocessor
Application: foil assist board, Efoil, electric surfboard, electric hydrofoil, underwater thruster, ROV, electric outboard, elcetric sup board, underwater robots, trolling mtor system, bow thruster, underwater jetpack, etc.,
Notice:
1. This ESC only compatible with the MTO6579-110-WPC or MTI65121 / MTI65162 / MTO70182 Motors
2. This ESC only support single direction (forward or reverse), if you want bidirectional, then please choose MTSF300A-WP32 bidirectional ESC



Strengths:
1. Fully new circuit design, excellent algorithm
--With high performance 32bit MCU processor, greatly improved data computing ability;
--Faster respond, smoother startup;
--Throttle linear is optimized, more accurate and smoother, better compatibility;
2. Seperate control board and power board design
--Elegant PCB layout and circuit design,control board won’t be influenced even when ESC gets heat at high power condition, which makes the ESC more reliable and has stronger anti-interference.
3. Support forward/reverse rotation
--The ESC filled with waterproof glue to make sure its IP68 waterproof, flat water cooling design to make sure high efficient heat dissipation.
--Suitable to use on various water sports like Efoil, surfboard, underwater thruster, etc.,
4. With kinetic energy recovery function
--Save more energy;
--Extend battery working time;
--Reduce heat
5. Multiple protections
--Startup protection;
--Over-temp protection;
--Low voltage protection;
--Phase loss protection;
--Signal loss protection
