MTSVESC6.0 200A VESC6.0 Based Controller 12S Lipo

  • Sale
  • $219.90
  • Regular price $258.70
Shipping calculated at checkout.


Customer Reviews

Based on 1 review
0%
(0)
100%
(1)
0%
(0)
0%
(0)
0%
(0)
M
Marcus Herold
Hard to find a substitute!

After having many failures with the original 4.12 60A VESC due to FOC caused DRV errors (I'm sure many can relate), I stumbled across this controller about 2 years ago. The price was hefty in comparison, but the performance it promised was unparalleled. Unfortunately, the claimed 200 amp of continuous current is very optimistic. I purchased a bluetooth module which allows me to connect the VESC to my phone, program, and monitor it. I found that its' readings are extremely accurate. I built an electric bike with a mid-drive motor setup, 50v Lipo graphene packs, and this controller. I did some testing with the setup, and found that on a day with about 70*F ambient temps, I could only pull about 100-120 amps continuous. Granted, this is much better than the previous controllers I have used, but it is not anywhere near the claimed 200 amps. When I tried to put this much current through the controller (full 200A), the motor would simply stall. I believe it is a limitation of the motor simply being overloaded and not the controllers' doing, but I thought I would mention it. I could only realistically output 180 amps; enough to get me to 30mph from a standstill in under 3 seconds! Bonkers fast for a deathtrap Ebike. But after about 10-15 seconds at this current, the temperature cutoff would quickly reduce my current to below 100 amps, and oscillate a few times before coming to a rest at 110 amps or so. I decided to take it upon myself to fix this overheating issue by removing the stock thermal pad which was on the backside of the MOSFETs, and thermal glued 6 individual copper pads (as if I did one slab, it would risk shorting the MOSFET's N-channels!). After this, I installed a new thermal pad, and also put huge heatsinks on the backside of the controller. These two mods allowed me to now pull upwards of 160 amps continuously; about 7-8 kilowatts! That's more like it. So unfortunately, if your build STRICTLY requires a continuous 200 amps, this controller (while otherwise quite a good buy) will not do it. Stock, I would guess 200 amps would only last for 8-12 seconds. The only other "gripe" I have with the controller is the micro USB port. After using that multiple times for programming with my computer, it BROKE off! I was stranded... until I bought the bluetooth module. Luckily, the Baud rate and firmware version that remained "bricked into" the controller talked to the new bluetooth module correctly. I was able to program it from then on with my phone (which I may say is a FANTASTIC buy, even though it is about $40-$50USD).
All in all, I do recommend this product. Just don't expect the level of performance it suggests, and be careful with the USB port! If you want to see it in action, check out my YouTube channel: Marcus Herold . I have 2 videos up as of now which are "Ebike vlogs" on my bike using this controller. "Riding with Nate!" is a much more comprehensive review because you can see much more details in the programming. I plan on uploading a video in the near future of the heatsink mods I made to it. Good luck with your projects!

Maytech 200A VESC6-based Speed Controller for Electric Skateboard Mountainbaord E-bike/E-scooter Powerful MTSVESC6.6 Lawnmower Robot/ Camera motorized dolly


Specification:

Model No.  MTSVESC6.0 Dust-proof Yes
Cont Current 200A Splash Waterproof Yes
Burst Current  240A BEC 5V/1.5A
Lipo Volt 3-12S Size 108*75*27mm
Hardware Based on VESC6.0 Firmware Updatable Yes
Connector  None Application Esk8/Robots/E-bike, etc.,



electric surfboard, underwater drone, electric hydrofoil, Underwater Propulsion Scooter, Underwater Propulsion Device, Diver propulsion vehicle, Electric jet board, electric wakeboard, electric SUP, Wakeboarding, Electric Hydrofoil Board, DIY Electric Hydrofoil Board, Electric Hydrofoil System, DIY VeFoil Kit, Electric Hydrofoil Boards, electric hydrofoil surfboard, efoils, motorized surfboard, eSurfScooter, electric watercraft, hydrofoilsurfing, Wakeboarding, Wakeskating, Wakesurfing, electric sportboats, electric outboard motors, sportboats, electric powered jet board,electric motorised jet board, electric powerd carbonfiber hydrofoil water craft, electric Yachts, electric hydrofoil board, electric flying surfboard, DIY electric hydrofoil, electric hydrofoil water taxi, Hydrofoil Bike, electric Hydrofoil Bike, water bike, DIY Electric Hydrofoil & Surfboard Remote Propulsion System, flying surfboard, all-electric hydrofoil speed boat,  E-surfboard, lightest motorized surfboard, Electric Foil Board, Water Sports, Electric kayak motors, Water jet propulsion devices, Electric SUP motors, Sea Scooter, stand up paddle board, Stand-Up PaddleBoards, WATER JET SYSTEM, jet-engine, powerful electric water sports gear,underwater thruster, Remote Operated Vehicle, ROV, ROV´s, ROV, Marine Outboard Engines, Underwater vehicle systems, Underwater vehicle components, underwater remotely operated vehicles, marine ROV, Submarine Propulsion Systems, Underwater Propulsion Device, Personal Propulsion System, Underwater Scooter, ROV thruster, Underwater Diving Scooter, rescue boat, motorized surfboard powered surfboard E-sup E-fin Electric sup Stand paddle paddle board Surfboarding  foiling  yachat racing boat

 fire fighting robots, DIY fire fighting robot, DIY fighting robots,  fighting robot, fighting robots, robot, robots, sumo fighting robots, Minibot battle,  Robot fight, robot fighting,  robot wars, war robots, BattleBots, Battle robots, robot battle, Robot combat, Giant Fighting Robots, Giant robot fight,

Electirc speed controller, VESC, benjamin vedder controller, controller for Esk8, controller for Electric skateboard,  SUPER esc, VESC_TOOL compatible controller, programmable VESC, VESC controller,  VESC6.0 based controller,  updatable vesc, speed controller,  Great start-up, dust-proof, splash waterproof, great start-up, canbus connection,  Compatible with sensored or sensorless motor,  high quality components construction,  SUPER FOC mode, BLDC mode, FOC mode,Giant robot, Giant Mech Battle, robotic combat and competition, robotic competition, competition robotics,  Robots fight, Robots fighting, Robotic Combat Competition, Robot battles, Combat robotics, Robot weapon,  110kg Weight class, 15kg Weight class, radio control,  Robotics combat,  DIY Robotic Kits, Fighting Robot Kits, Robot Kits, Lightweight Combat Robot Kit, Battlekit, Mini-Sumo Robot Kit, Vertical Spinner robots, heavyweight Robot Wars fighting machine, battle robot kit, rc robot battle, robot war, heavyweight robots, featherweight robots,fire fighting robots, DIY fire fighting robot, DIY fighting robots,  fighting robot, fighting robots, robot, robots, sumo fighting robots, Minibot battle,  Robot fight, robot fighting,  robot wars, war robots, BattleBots, Battle robots, robot battle, Robot combat, Giant Fighting Robots, Giant robot fight,Electric skateboard, Esk8, Electric longboard, Elongboard, Electric board Electric mountainboard, all terrain offroad skateboard, Eskate, skateboard, outdoor skateboard, motorized skateboard, motorized board, motorized mountianboard, powered skateboard, city skateboard, street skateboard, hover board, E-bike, electric bike, electric bicycle, electric scooter, e-scooter, e-mountainbike, electric mountainbike, electric vehicles, electric tools,Electric skateboard, Esk8, Electric longboard, Elongboard, Electric board Electric mountainboard, all terrain offroad skateboard, Eskate, skateboard, outdoor skateboard, motorized skateboard, motorized board, motorized mountianboard, powered skateboard, city skateboard, street skateboard, hover board, E-bike, electric bike, electric bicycle, electric scooter, e-scooter, e-mountainbike, electric mountainbike, electric vehicles, electric tools,Electric skateboard, Esk8, Electric longboard, Elongboard, Electric board Electric mountainboard, all terrain offroad skateboard, Eskate, skateboard, outdoor skateboard, motorized skateboard, motorized board, motorized mountianboard, powered skateboard, city skateboard, street skateboard, hover board, E-bike, electric bike, electric bicycle, electric scooter, e-scooter, e-mountainbike, electric mountainbike, electric vehicles, electric tools,

firmware is updatable programmable, application VESC for drone, electric bike, rc car, rc helicopter, agricultural robots, mountainboard bike, go-kart, multi-copter, parking system, electric vehicles, fighting robots, printing device, fishing boat, rc airplane, monitoring robots, security robots, cable camera, fishing boat,firmware is updatable programmable, application VESC for drone, electric bike, rc car, rc helicopter, agricultural robots, mountainboard bike, go-kart, multi-copter, parking system, electric vehicles, fighting robots, printing device, fishing boat, rc airplane, monitoring robots, security robots, cable camera, fishing boat,Attention Points when you receive the VESC Please:
All products had been double checked and tested one by one before shipment, only if the products are working normally would be shipped out.
    • When you receive the VESC, please test without load and do not connect motor, first check if the VESC can successfully connect to your computer, if ok, then connect to motor and you can start to adjust parameters.
    • Do not use switching power supply, the instant voltage when switching power supply connect to VESC is very high, which would easy damage the VESC.
    • Do not push the throttle too hard when test without load, gently and slowly speed up.
    • Be cautious when adjust parameters, if parameters set mistake, would also easy damage the VESC.
    • Please must remember to change to corresponding modes when you adjust parameters, for example, the VESC default mode is BLDC mode, but if you want to detect FOC mode and adjusted FOC parameters, at this time if mode in VESC_TOOL didn't change to FOC mode, then when you push throttle, would easy burn the VESC, same as FOC mode.
    • In FOC mode, ERPM suggest to control in 30000-40000; In BLDC moed, ERPM suggest to control in 50000-60000, otherwise driver IC would easy to be damaged. ERPM= motor pole pairs number * KV * Voltage
      ERPM= motor pole pairs number * KV * Voltage
    • If you use UART port, the wire better do not over 0.5m or even shorter, and better use Stranded wire.
    • For V4 based VESC:

              Do not suggest to use FOC mode, suggest to use BLDC mode.
              If need to use FOC mode, then must use voltage under 20V.

    • The above are only suggestions based on the experience of our engineers. how to actually operate is up to you. Parameters for different setup is also different, please noted

Application:

Electric skateboard, Esk8, Eskate, Elongboard, Mountainboard, Offroad skateboad, All terrain skateboard, Eskate, E-bike, Electric bike, Electirc motorcycle, E-scooter, Electric scooter, motorized skateboard, ROV/RPVEE, Remote operated vehicles, underwater robots, Underwater robotics, Underwater remotely operated vehicles, Subsea robots, Cablecam, Cable camera, Broadcast, IBC2019, Ultra drones, Security monitoring robots, Robots for security and safety monitoring in harsh terrain, Agile robots, Autonomous agile robots, Security robots, Autonomously monitor security, Combat robots, Fighting robots, Electric surfboard, Efoil, etc.,
