Maytech 23KW Powerful Marine Engine 120180 Watercooled Inrunner Motor for Electric Boat Surfboard
Maytech 23KW Powerful Marine Engine 120180 Watercooled Inrunner Motor for Electric Boat Surfboard
Regular price
$1,015.50 USD
Regular price
Sale price
$1,015.50 USD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
Maytech 23KW Powerful Marine Engine 120180 Watercooled Inrunner Motor for Electric Boat Surfboard
Specification:
| Model No. | MTI120180 | Idle Current | 3.2A/8.4V |
| KV | 120, can be customized, contact eileen@maytech.cn | Max Current | 340A |
| Input Volt | 8-18S Lipo (33.6-75.6V) | Max Output Watt | 23.3KW |
| Construction | 12N/10P | Motor Weight | 6.64kg |
| Motor Touque @60% | 28.6 N.m | Shaft | Keyway Shaft |
| Cooling Method | Water Cooling | Shaft Diameter | 13mm |
| Shaft Output Length | 49.5mm | Cable Guage | 6AWG |
| Max Effeciency | 91% | Cable Length | 1m |
Stock Notice before Place Order:
The motor is not regular stock item, MOQ is at least 10pcs, lead time is around 50-60 working days after payment confirmed, please email to eileen@maytech.cn for more information.
Application:
Electric surfboard/Efoil/Hydrofoil/jetski/jetboard/waterboard/water jet propulsion/surffoil/foilsurf/foilboards/rc boat, foil boat, foiling boat, hydrofoil boat, hydrofoiling boat, rescue boat, etc.,
Test Datasheet:
